DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating

Certification : CE, ISO

MOQ : 1

Price : 4000

Brand Name : OURUIDA

Model Number : DSP-35KW

Place of Origin : CHINA

Payment Terms : Western Union,T/T,D/P,D/A,L/C

Supply Ability : 10000

Delivery Time : 1-5

Packaging Details : Export wooden boxes

Model NO. : DSP-35KW

Type : Induction Heating Machine

Structure : Vertical Type

Application : Heating, Quenching, Forging, Melting, Welding

Power : 35kw

Frequency : 15-35kHz

Input Current : 53A

The Range of Operating Voltage : 340-430V AC

Size : 620*320*500

Weight : 50kg

Work Power : 3*380V/415V/440V/480V 50-60Hz

Testing Temperature : 2 Chanines

Cooling Way : Air Cooled

System : IGBT

Transport Package : Wooden Box

Specification : CE, SGS, ISO

Trademark : ORD

Origin : China

HS Code : 8514400090

Production Capacity : 10, 000sets

Contact Now

DSP-35KW Digital Air Cooled Induction Heater
Advanced digital induction heating machine designed for preheating before welding, PWHT (Post Weld Heat Treatment), oil pipe heating, and heating expansion/shrink applications.
DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating
Key Advantages
  • Over 22 years of manufacturing experience ensuring stable performance
  • CE certified for quality and safety standards
  • Fully digital control system
  • 8-section heating capability
Main Characteristics
Front panel features LCD touch screen, key controls, and power switch with full digital display. Compatible with switch signals for start/stop control and PLC power regulation via industrial interfaces.
Visual human-computer interface provides intuitive operation with flexible integration capabilities for robots, automation equipment, and remote control systems.
Remote control functionality with digital circuit control allows power adjustment from 0% to 100% resolution. Optional digital PID temperature control module enables automatic target temperature setting with ±1°C accuracy.
Five Operating Modes
  • Manual: Direct on/off switch control
  • Timer: Set heating duration with automatic stop
  • Fixed Temperature: Heat to preset temperature then stop
  • Constant Temperature: Automatic power adjustment to maintain set temperature
  • Section Heating: 8 programmable sections (S1-S8) with individual power, timer, and temperature settings
Nine programmable memory slots (P1-P9) store settings for different workpieces, enabling quick selection and efficient operation.
DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating
Technical Specifications
Type DSP-35KW
Work Power 3*380v/415v/440v/480v 50-60hz
Operating Voltage Range 340-430V AC
Output Power 35KW
Input Current 53A
Fluctuating Frequency 15-35khz
Timing (Heat/Retain/Cool) 1-9999S
Heating Sections 8 Sections
Water Temperature Protection 40°C
Duty Cycle 100% (40°C room temperature)
Weight 50KG
Size 620*320*500MM
Customer Service Commitment
Pre-Sale Services
  • Expert machine selection based on customer requirements
  • Comprehensive inquiry and consulting support
  • Sample testing services
  • Factory viewing opportunities
In-Sale Services
  • Manufacturing to relevant technical standards
  • Comprehensive run testing per equipment regulations
  • Rigorous quality inspection before delivery
  • Guaranteed on-time delivery
After-Sale Services
  • 18-month warranty from delivery date / 12-month warranty from receipt date
  • Free replacement of all parts within warranty for non-artificial faults
  • Technical maintenance visits for major quality issues beyond warranty period
  • Lifetime cost pricing for materials and spare parts
  • Extended quality assurance and operational guarantees
DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating DSP-35KW Digital Type Air Cooled Induction Heating Machine for Preheating Before Welding and Oil Pipe Heating
